What is 2D drawing?

In the past, 2D drawing was done using a pencil, paper, and a ruler. Today, there is much software that allows the user to create 2D drawings in CAD format

A 2D drawing is a geometric figure created by two-dimensional lines called vectors, containing various GD&T symbols. It is commonly used in architecture and design to represent 3D objects and structures on paper or a computer screen.

What is CAD drawing?

A CAD drawing (computer-aided design)  is a detailed 2D or 3D illustration displaying the components of an engineering or architectural project. The computer-aided design utilizes software to create drawings to be used throughout the entire process of a design project, from conceptual design to construction or assembly.

Why is 2D drawing important in mechanical engineering?

2D drawings are useful in mechanical engineering for many reasons. They are a great way to show the design process and help ensure all product features are seen. They also provide a way for engineers to share their designs with other people who are not able to see them in 3D without expensive equipment.

  • It is a way to communicate with other people and share ideas
  • It is a way of visualizing the design process and showing how things will work together
  • It can help ensure that you are designing in the most efficient way possible, which saves time and money later on in the project.
  • It’s a way to plan the details before starting work on them, which saves time and money because you’re not accidentally making too many mistakes or having to redo things later in the project for no reason.
  • It can save you time in production because it helps you make sure everything is ready for production before you start it, which means fewer delays or mistakes that could have been avoided if you had planned ahead of time instead of waiting until everything was done. was ready at once before starting production.

WhatsApp Image 2022 12 16 at 21.12.32

What is 3D drawing?

3D drawing is a process of creating 3D objects using digital software and a 3D model. It is a modelling technique that uses geometric descriptions to represent three-dimensional objects in an electronic format for 3D printing, computer graphics, film, etc.

In the early days of digital technology, 3d drawings were done manually by hand sketches or 2d drawings. But now it has been turned into a digital tool that can be used with software like 3ds Max, Blender, Maya and SolidWorks.

What is the difference between 2D and 3D drawings?

Today, we see artists and painters drawing in 2D and 3D. The difference between the two is that 2D is a flat image whereas 3D is one that has depth

People often confuse these two different forms of drawing. But they are different in many ways. Sometimes, people tend to mix 2D and 3D drawings because they both use lines to create shapes and objects. However, 3D drawings are three-dimensional while 2D drawings are flat on one or both sides.

2D drawings are based on outlines that are usually connected to each other to create shapes and objects while 3D drawings use solid lines without overlapping each other.

3D drawings are created using computer-generated graphics such as 3ds Max, Blender, Maya and SolidWorks. In contrast, 2D drawings are created with pencil or pen over physical paper, ink or paint (can still be created with CAD software).

Why is 3D drawing better than 2D drawing?

The big progress of 3D drawing is that we can visually see all details and measure any dimensions in 3D model drawing, and also make 3D printing prototype samples with 3D drawing, 2D illustration is useful when you only want a general view of a certain type. Measured 3D drawings can be easily converted to any 2D drawing, but 2D illustrations will not be converted to 3D drawings.

3D is all about perspective

What is a 3D image

What is virtual reality?
